supply linear moving single-position hot bar soldering machine CWPP-1A CWPP-1A manufacturer from China DongGuan City Aoleder Automation Technology Co., Ltd.

supply linear moving single-position hot bar soldering machine CWPP-1A

Price:	1.0~6200.0 USD
Payment Terms:	T/T,L/C,
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: CWPP-1A

Production Capacity: 30sets/Month

Delivery Date: Within 7days after receipt ...

hot pressing temperature method: Pulse Heat

Means of Transport: Ocean,

Packing: seaworthy plywood case,safe...

Brand Name: Chuangwei

Chuangwei hot bar soldering machine
1.use pulse heat with linear guide moving
2,apply to TAB,TCP,ACA and FPC,FFC,PCB etc.

Chuangwei hot bar soldering machine

1.use pulse heat with linear guide moving

2,apply to TAB,TCP,ACAand FPC,FFC,PCB etc.

Chuangwei hot bar soldering machine

Technology parameters

Model: CWPP-1A

Max. Working Area:200mm X 260mm

Fixture: 1 set

working air pressure:0.45-0.7Mpa

voltage and power:110V/220V 2000W(moment)

momentary welding Power:2000w

Temperature setting:20-500℃

Temperature precision: ±2℃

hot-pressing time:1-99 s

force head pressure: 0.1-0.6 MPa

Size:620mm X 690mm X 570mm

Weight: 90Kg

Chuangwei hot bar soldering machine Feature:

1.Closed Loop PID temperature control with visible LED display

2.LCD display programmable pressure switch for precise force control

3.Each heating cycle is triggered by a real time pressure sensor

4.Floating thermode ensures consistent pressure and heat transfer

between the thermode head and the parts to be joined

5.Silicon rubber can be fitted in bonding Heat Seal Connectors

between LCD and PCB

6.Standard workpiece holder is mounted on a linear guideway and

designed to allow for easy changeover and repeatable operation

7.Parts registration is adjusted by micrometer and secured by vacuum

lock

8.Optional CCD system for fine pitch component
